Brushless ESC RCE-BL80X


Availability:
Ready to send: 3-5 days
Appeared on: 26/06/2017
Art. Nr: HES80X01
Category: Align


... Continue reading

120,99 €

Inc. Vat 21.00%, include Shipping

Notify me when available Avisar

Quantity : Note Not available!

• BEC output voltage(6~8.4V) to show great performance on the torque & speed of servo.
• BEC output utilizing switching power system,suitable for 2S~6S Li battery,with continuous current rating of 5A,and burst rating of 7A.
• Three programmable throttle speed settings to support quick throttle response.
• Govener Mode(governor speed controller、slow down system).
• Small and compact PCB design for ease of installation.
• Large heatsink for great thermal performance.
• High compatibility to work with 98% brushless motors in the market.
• Ultra smooth motor start design to run with all kinds of brushless motors.
• The power inlet adapts Japanese made "Low ESR" capacitor in order to provide stable power source.
• Users can use the transmitter to operate the motor setting by Super stylized CPU.


Specifications


• Contimuous current: 80A
• Surge current: 100A
• Supporting motor types: 2 poles to 10+poles in/outrunner brushless motors
• Supporting maximum RPM: 2 poles=>190,000rpm
• Supporting maximum RPM: 6 poles=>63,000rpm
• Supporting input voltage: 2S~6S
• Supporting battery types: Li-ion/ Li-poly 2~6 cells
• BEC output:dual BEC output 6~8.4V,current 5A
• Size: 53X33.8X18.7mm
• Weight: Approx. 86g


Content


• 1x Align RCE-BL80X Brushless BEC
• 3x ALIGN standard 4mm socket terminal (Max. current 110A)
• 3x Heat shrink tube (4x25mm)
