OXY3 Sport - No Main Blades

OXY 3 – 270 Pro – The newest OXY3 is finally HERE!

Design base on the NEW OXY3 – Tareq Edition, the OXY3 – 270 Pro represent the base option of the newest OXY 3 2018 Series Edition.
Using the best compromise of Quality CNC and Copolymer Parts, the new OXY3 – 270 Pro improves the performance of his older brother, the OXY3 – 255.

Many of you confused by the interest for the improvement of the new OXY3 – 270 Pro, but more ask: “How was possible to improve a product already perfect?”

OXY Factory Pilots and Luca worked on advanced Heli specification, and the result after over 10 months of hard work is now easy touchable… not just for beauty but especially in flight.

Major changes applied compared the OXY3 – 255:

1-     Main Blade:  Thanks to important design in cooperation with ZEAL, Luca defined an innovative skin blade Airfoil, combined with a Variable Profile geometry that optimizes the airflow speed along the blade length, reducing drag effect giving the “clean and precise” feeling that each PRO Pilot looking for. This resulted in the new design named Vari-Pro (Variable Profile). The improved efficiency over old 255mm Blades, gives the possibility of a 3 or 4 S Powered OXY3 to spin without limitation to 273mm Blades. Without scarifying fly time and amaze the performance. All of these changes gives an obvious and touchable improvement of fly feeling effect.

2-     Simplicity to Efficiency… Over three years of experiences on the OXY3 – 255 help us to define new features and make all manual operations easier.
-  Main Gear Jesus Bolt: Those who have an OXY 3 already knows what we are talking about. YES, we did! New Design, were no pliers are necessary on the lock / unlock operations. Already used and approved on our OXY 4 a special OEM Nut called H2-M2 helps dramatically assembly and service operations.

- DFC Linkage Rods, some of you as us, probably experienced a nasty feeling after crash, the impossibility to reuse Main Grip with the DFC fastening screw snapping off in it!
In the new OXY editions, we introduce a “clever” and innovative system with superiors fastening and kinetic features. In case of a hard crash, assure the integrity of the Main Grip with the possibility of easy and fast service of every single DFC / Head and parts.

Simple detail made big improvements!

3-     Improved CoG (360-degree Center Of Gravity):  Extra battery volume, better visibility and “Muscle” Kit Sexy Look.  Improved CoG position.  The perfection maybe not exist, but OXY Team and Luca aim for that!
- New frame design, combined with a new profile canopy is the answer. More space for battery and ultimate sexy look!

- Standard is Stretch... The NEW OXY3 – 270 Pro comes standard Stretch. This makes it easy for you choose the blade, from 255mm up to 287mmm as with the new Tareq Edition.           OXY3 – 270 will support your personal choice


4-     Tail System Efficiency:  For Oxy Heli the Tail was and will be the most important Heli feature to handle.
- The New OXY3 – 270 Pro feature new tail components and tail ratio. With all new components, together with the improved efficiency we also improved the vibe suppression, holding and the wear resistance.

OXY 3 – 270 Pro – Specifications List:

FRAME AND CANOPY:

- New Fiber Glass canopy design, optimized volume and aggressive look.
- New Frame Design improves CG, battery volume capability and stiffening.
- Triple Main Shaft Bearing Block Support System.
- Ultra-Light and flexible landing gear - Copolymer based material
- POM Copolymer main gear with innovative Jesus H2-M2 Nut System.
- Carbon / Copolymer Anti-rotation guide.
- All aluminum parts with special surface finish and anodize black color.

HEAD SYSTEM:

- New main blade Carbon Fiber Zeal Vari-Pro 273mm Orange Touch.
- DFC Head System with innovative fastening lock system.
- All aluminum parts with special surface finish and anodize black color.
- Optional FBL System Head available, sold as optional.

TAIL SYSTEM:

- Polymeric OXY HELI Profile Boom System.
- New improved Tail Grip and Tail ratio System.
- Plastic Black 50mm Tail blades.
- All aluminum parts with special surface finish and anodize black color.

EXTRA PART AND ACCESSORY THAT COMES WITH THE KIT:

- Swashplate leveler tool.
- 11T and 14T pinions.
- Vertical fins colored stickers

OXY3 – 270 Pro Kit comes without any electronics, giving you the best option to choose the power system you want.
