Tarot 5.8G 600mw FPV transmitter combo TL300N


Disponibilidad:
Listo para enviar: 1 a 2 días laborales
Aparecido el: 26/02/2015
Art. Nr: FYTL300N
Categoría FPV Tx/Rx


... Seguir leyendo

68,00 €

Inc. 21.00% IVA., incluir Envío
Cantidad: Nota

Tarot developed 32 frequency points! 600mw 5.8g image transmission system with super mini size and light weight form factor, especially for small-scale multi-axis rotary wing aircraft as well as the current through the machine. 32 is compatible with conventional frequency frequency to provide a video signal, two-way audio signals long distances, while providing 5V1A power output (can be used for image overlay, video cameras supply. Make sure the voltage and current in order to avoid burning out the TX its transmitter weight 8.3g only (excluding antenna).

Please note your warrenty is invalid if voltages over over 5v have been applied to the TX

Transmitter detailed parameters: Specifications:
1, NW 8.3G (excluding antenna) Weight: 8.3G (without antenna)
2, volume 21 * 33 * 7.5MM Dimension: 21 x 33 x 7.5 mm
3, the transmission frequency: 5645-5945MHZ / Working Frequency: 5645-5945MHz
4, the number of channels: 4 bands, a total of 32 channels Channel: 4 bands / 32 channel
5, the channel selection: 5 mini-DIP switch 5-DIP switch
6, transmit power: 27.5 dbm (600mw) Output Power: 27.5 dbm (600mw)
7, the input voltage: 7-26V DC (2-6S) Input Voltage: DC 7-26V (2-6S)
8, the output voltage: 5V 1A / Output Voltage: 5V 1A
9. Antenna Interface: SMA 50Ω / Antenna Adaptor: SMA 50Ω
10. Working temperature: -10 to 60 degrees Celsius. Working Temperature: -10 ~ 60 degrees.
11, the modulation type: FM Frequency: FM

Receiver Detailed parameters: Specifications:
1, NW 10.9G (excluding antenna) Weight: 10.9 G (without antenna)
2, volume 28 * 46 * 10MM / Dimension: 28 x 46 x 40 mm
3, receiving frequency: 5645-5945MHZ / Working frequency: 5645-5945 MHZ
4, the number of channels: 4 bands, a total of 32 channels Channel: 4 bands / 32 channels
5, the channel selection: 5 mini-DIP switch 5-DIP switch
6, the receiver sensitivity: -85 dbm / Receiving Sensitivity: -85 dbm
7, the input voltage: 7-26V DC (2-6S) / Input Voltage: DC 7-26V (2-6S)
8, Antenna Interface: SMA 50Ω / Antenna Adaptor: SMA 50Ω
9, the working environment temperature: -10 to 60 degrees Celsius. Working Temperature: -10 ~ 60 degrees
10, the modulation type: FM / PLL Frequency: FM / PLL
11, audio and video output interface: 2.5mm audio and video plug AV output: 2.5mm 4 pins AV output
12. Power Connector: 3.5mm inside the outer 1.3mm DC power plug Power input: 3.5mm (exterior) 1.3 mm (interior) DC
